Technical Support

1. Make sure the truck is parked with an unobstructed view to the southeastern sky (i.e., tree, telephone pole, building, trailer and/or other tractors). If needed, move the truck to ensure the dome has a clear line of sight.
2. Plug the TV and receiver into a power strip (not included).
3. Flip the power strip switch to the ON position.
4. Check to make sure the blue light on the front of the receiver is lit.
5. Turn the satellite dish on by flipping the wall plate switch to the “on” position. (If you don’t have a wall plate switch, simply plug the 12-volt adapter into the cigarette lighter.)
6. Wait 5 minutes for the receiver to boot up and display programming.

Note: By default, these settings should have been setup during installation. As such, only use the following instructions if you have inadvertently changed your satellite settings or if you are troubleshooting.

1. Press the MENU button on your white DIRECTV remote.
2. Scroll down to SETTINGS & HELP.
3. Select SETTINGS.
4. Select SATELLITE.
5. Select REPEAT SAT SETUP. (If required press the DASH symbol “–” which is located below the # 7 on your remote.)
6. Make sure the following types are selected:
   • DISH TYPE set to 18" LNB.
   • RB/INTL set to NONE SELECTED.
   • SWITCH TYPE set to 02 MULTISWITCH
   • TUNERS set to DUAL.
7. Then select the SATELLITE SIGNAL.
   • If most of the transponders show a number other than 0, select DONE and continue to Step 8.
   • If every other transponder is showing 0, return to the fleet for troubleshooting help.
   • If all transponders show 0, flip the wall plate switch or unplug the cigarette lighter to turn off the EPICVUE dome and then turn it back on. Wait 2 minutes while the dome locks onto the satellite signal. If all transponders still show 0, refer to the Troubleshooting section and start with step #1 under Error Codes. Note: If the dome does not seem to be moving or making any noise, then there is a power issue. Check your fuses or return to the fleet for help.
8. Select CONTINUE to verify the setup.
9. Once you have verified the setup, download the program guide. When the status bar reaches 100%, select CONTINUE.

1. Push the OFF button on your white DIRECTV remote.
2. Flip the power strip switch to the "off" position and unplug the DIRECTV receiver plug from the power strip. This ensures that no power is sent to the DIRECTV receiver.
3. Turn the EpicVue dome off by flipping the wall plate switch to the “off” position. If you don’t have a wall plate switch, simply unplug the 12-volt adapter from the cigarette lighter.

1. With the TV on, press the INPUT button on the black TV remote.
2. Select antenna mode.
3. Press the SETTINGS button on the black TV remote.
4. Select CHANNEL.
5. Select AUTO TUNING.
6. Select YES.

1. With the TV on, press the SOURCE button on the black TV remote.
2. Select TV as the source.
3. Press the MENU button on the black TV remote.
4. Select BROADCASTING.
5. Select AUTO PROGRAM.
6. Select Start.
7. Set Antenna to Air.
8. Select SCAN.

1. Press the MENU button on your remote.
2. Scroll down to the SETTINGS & HELP.
3. Select SETTINGS.
4. Scroll down to REMOTE CONTROL.
5. Select PROGRAM REMOTE.
6. Select TV TYPE.
7. Enter the model number on the back of your TV.
8. Follow the instructions on the TV screen.

1. To record a single episode, press the RECORD button on your remote once.
2. To record an entire season, press the RECORD button on your remote twice.

1. Press the LIST button on your white DIRECTV remote.
2. Scroll through recorded shows.
3. Select desired show; press SELECT on the remote.

Error Codes

• The following error codes indicate a receiver re-authorization is needed: 711, 721, 722. Please contact EpicVue Customer Service (866) 900–4434.
• The following error codes indicate the EpicVue dome is not locking onto a signal: 771, 772. Please see the instructions below for troubleshoot tips.

1. Make sure the truck is parked with an unobstructed view to the southeastern sky (e.g., away from trees, telephone poles, buildings, trailers and/or other trucks). If needed, move the truck to ensure the dome has a clear line of sight.
2. Turn DIRECTV receiver off.
3. Power down the satellite dish by flipping the wall plate switch or unplugging the cigarette lighter.
4. Check the coaxial cables to make sure they are securely connected. One of the coaxial cables should be connected from the MAIN PORT on the EpicVue dome to the INPUT 1 outlet on the back of the DIRECTV receiver. The other cable should be connected from the SEC PORT on the EpicVue dome to the INPUT 2 outlet on the back of the DIRECTV receiver. You can distinguish between these two cables by identifying the cable that has the fine white print on it and tracing it first.
5. Check that the HDMI cable is securely connected to the receiver and the TV.
6. Press the INPUT button on the remote and make sure the correct MODE has been selected (i.e., HDMI for DIRECTV programming or TV for local area channels).
7. Turn the DIRECTV receiver and satellite dish back on. Wait 5 minutes while the receiver boots up to display programming.
8. Lastly, double check the satellite dish settings as previously outlined under the EPICVUE DOME section.

• Always power down the EpicVue dome before driving; failure to do so will damage the dome.
• The standard operating temperature of the satellite dish is -13F or above.
• Movies OnDemand and Pay Per View services are not available with this package.
• The NFL Sunday Ticket (700 channel series) is only available during the NFL season.
